Fiche technique :
| Caractéristiques générales | |
| Type | Online |
| Capacité | 1000VA / 800W |
| Facteur de puissance sortie | 0.80 |
| Input | |
| Gamme de tension d’entrée | 110-300 VAC at 50% load 160-280 VAC at 100% load |
| Input PF | ≥ 0.99 at full load |
| Gamme de fréquences | 40Hz – 70Hz (self-adaptive to 50/60Hz) |
| Frequency (Synchronized Range) | 47Hz – 53Hz or 57Hz – 63Hz |
| Sorties | |
| Tension de sortie nominale | 200/208/220/230/240 VAC |
| Onde sinusoïdale pure | Yes |
| THDv | ≤3% Full Linear Load; ≤6% Non-Linear Load |
| Régulation de tension (Bat. Mod.) | ±1% |
| Frequency (Battery Mode) | ±0,3Hz |
| Détails techniques | |
| Load Crest Ratio | 3:1 |
| Transfer Time [AC to Battery] | 0ms |
| Transfer Time [Inverter to Bypass] | 4ms |
| Generator support | Yes |
| Overload Capacity | N/A |
| Connection Batteries Externe | Yes |
| Charger | 1A |
| Fan Logic | Always on, automatic speed control |
| LCD Indicators | UPS status, Load level, Battery level, Input/Output voltage, Discharge Timer, fault conditions |
| Efficacité | |
| LINE mode full Load | 88.0% |
| Batteries et temps d’autonomie | |
| Batteries | 2x 12V/9Ah |
| DC Voltage | 2 x 12V |
| Recharge Time | 9h to 90% |
| Full Load Backup Time | 4min |
| Half Load Backup Time | 11min |
| Connexions et communication | |
| IEC C13 Outlet | 3 |
| Input | C14 |
| Logiciels | ViewPower |
| USB port | Yes |
| RS-232 Port | Yes |
| Extension Slot | Yes, 1 |
| Environment | |
| Niveau de bruit | < 50dB |
| Températures | 0°C – 40°C |
| Humidité | 20% – 90% RH (non-condensing) |
| Logistique | |
| IEC 62040-3 classification | VFI-SS-111 |
| Contenu du colis | UPS, Manual, USB Cable, Input Power Cable, Tower Holder, Rack Ears |
| Languages du manuel | EN/DE/PL |
| EAN | 4260074977172 |
| Largeur | 438 mm |
| Hauteur | 88 mm |
| Profondeur | 310 mm |
| Poids | 12 kg |
| Giftbox – Largeur | 500 mm |
| Giftbox – Hauteur | 180 mm |
| Giftbox – Profondeur | 400 mm |
| Giftbox – Poids | 13.5 kg |
| Pcs. per box | 1 |
| Pcs. per layer | 6 |
| Pcs. per pal | 40 |
